Autonics Digital Panel Meter DC Ampere, MT4W-DA-40

Multi panel meter MT4Y/MT4W series has various functions such as AC frequency measuring function, zero adjustment function and transmission output scale function. This series is the super version of panel meter which realizes -1999 to 9999 max display range, wide power supply range and various output option selection

General Characteristics

• Super version panel meter
• Various output options (Default : Indicator) : RS485 communication output, low speed serial output, current(4-20mA) output, BCD output, NPN/PNP open collector output, relay output
• Max. measuring input specification : 500VDC, 500VAC, 5ADC, 5AAC
• Max. display range : -1999 ~ 9999
• Prescale function
• AC frequency measurement (0.1 ~ 9999Hz)
• Various functions : Monitoring for max./min. display value function, Display cycle delay function, Zero adjustment function, High display correction function, Current output scale function, etc.
• Wide range of power supply : 100-240VAC, 12-24VDC(MT4W only)
