Autonics Counter/Timer 5 Digits W48xH48mm, FX5S-I-12-24VAC/VDC

Autonics Counter / Timer, Up / Down 5 Digits LED, DIN W48xH48mm, Supply: 12-24VAC/VDC, Indicator Only

DIN W48×H48mm compact size up/down counter/timer FXS series provides 1cps/30cps/2kcps/5kcps of counting speed and supports NPN/PNP input selecting function and decimal point selecting function (fixed decimal point of display). Also, the series is possible to set various up/down counting modes so that various user applications can be supported.

General Characteristics

• Upgraded counting speed: 1cps/30cps/2kcps/5kcps
• Selectable voltage input (PNP) or No voltage input (NPN)
• Addition of Up/Down input mode
• Available to set a decimal point (Fixed decimal point of display)
• Wide range of input power supply: 100-240VAC 50/60Hz, 12-24VAC/DC(Option)
• Selectable Counter/Timer by internal DIP switch
• Various time ranges
• Built-in Microprocessor
