Carlo Gavazzi Timer Star-Delta Plug-In S115186230

Carlo Gavazzi Timer Star Delta, Range: 0.15s-800s, Plug-In, SPDT With Neutral Centre, S Housing, Supply: 230VAC.

Multi time range, plug in star-delta control relay with 4 selectable time range up to 800s, Used in application where motor are started in star-delta configuration such as large blower etc.

General Characteristics

• 4 selectable time ranges: 0.15 s to 800 s.
• Automatic start.
• Knob adjustable time within range.
• Fixed delay between star and delta output.
• Oscillator-controlled time circuit.
• Repeatability deviation: 1%.
• Output: 2x 10 A SPDT relay.
• Plug-in type module.
• S-housing.
• LED-indication for star and delta outputs.
• AC or DC power supply.
