Carlo Gavazzi Timer Multi-Functions Din-Rail DMB51CM24B006

Carlo Gavazzi Timer Multi-Functions, 7 Functions, Range: 0.1s-100h, Mini-D DIN-Rail, SPDT, Supply: 24VDC and 24-240VAC, Option: B006.

Multi-voltage timer with 7 knob selectable functions and 7 knob selectable time ranges within 0.1s and 100h. For mounting on DIN-rail. Housing 17.5 mm wide for SPDT version and 35.5 mm for DPDT version, suitable both for back and front panel mounting. Wide power supply range: 24 VDC and 24 to 240 VAC or 12 to 240 VAC/DC.

General Characteristics

• Time range 0.1 s to 100 h.

• 7 knob selectable functions:

• Op - delay on operate.
• In   - interval.
• Io   - interval on trigger open.
• Id   - double interval.
• Dr  - delay on release.
• R   - symmetrical recycler ON first.
• Rb - symmetrical recycler OFF first.

• Automatic or manual start.

• Repeatability: ≤ 0.2%.

• Output: 5 A SPDT or 5 A DPDT relays.

• For mounting on DIN-rail in accordance with DIN/EN 50 022.

• 17.5 mm (DMB51C) or 35.5 mm (DMB71D) DIN-rail housing (DIN 43880).

• Combined AC and DC power supply.

• LED indication for relay status and power supply ON.
