Carlo Gavazzi Monitoring Relay Voltage 1-Phase Din-Rail DUB02CT23

Carlo Gavazzi Monitoring Relay 1-Phase True RMS AC/DC Over/Under Voltage, DIN-Rail, SPDT, Supply: 24, 115, 230VAC.

DUB02 and PUB02 are precise TRMS AC window voltage monitoring relays. The relays monitor their own power supply which is selectable by DIP-switch (24, 115 or 230 VAC). The advantage of using the latch function is that the relay can be kept energized even after the end of the alarm condition. Inhibit function can be used to avoid relay operation when not desired (maintenance, transitions). The LED's indicate the state of the alarm and the output relay.

General Characteristics

• TRMS AC over/under voltage monitoring relays
• Measuring if power supply is within set limits
• Measure their own power supply
• Measuring ranges: 24, 115, 230 VAC
• Power ON delay 1 or 6 s selectable by DIP-switch
• Separately adjustable upper/lower level on relative scale
• Adjustable delay on alarm or on recovery (0.1 to 30 s)
• Programmable latching or inhibit at set level
• Output: 8 A SPDT relay N.D. or N.E. selectable
• For mounting on DIN-rail in accordance with DIN/EN 50 022 (DUB02) or plug-in module (PUB02)
• 22.5 mm Euronorm housing (DUB02) or 36 mm plug-in module (PUB02)
• LED indication for relay, alarm and power supply ON
