Carlo Gavazzi Monitoring Relay Current/Voltage 1-Phase Plug-In S180156230

Carlo Gavazzi Monitoring Relay 1-Phase, AC/DC Current/Voltage, 1mA-5A, 50mV-500V, S Housing, Plug-In, SPDT, Supply: 230VAC.

Universal AC/DC current and plug-in voltage metering relay. Built-in time delay with both delay on operate and on release. Exchangeable module for different ranges and values. Latch function and external adjustment of hysteresis. For a wide range of applications.

General Characteristics

• AC/DC current/voltage control relay
• Code module for 7 current ranges (1 mA - 5A)
• Code module for 13 voltage ranges (50 mV - 500 V)
• Switch for selection of AC/DC measuring
• Built-in adjustable timer function: delay on operate and delay on release
• Maximum or minimum level detection
• Latching at set point possible
• Output: 10 A SPDT relay
• Plug-in type module
• S-housing
• LED-indication for power supply and output ON
• AC power supply
