Carlo Gavazzi Monitoring Relay Current 3-Phase Din-Rail H475156400

Carlo Gavazzi Monitoring Relay 3-Phase Max. and Min. Current Control, CT Type A74, H Housing, DIN-Rail, SPDT, Supply: 400VAC.

3-phase current metering relay with separate setting of upper and lower current level. For DIN-rail mounting. Often used where a certain application such as a large mixer has to be kept within a set current value in order not to overload the system.

General Characteristics

• 3-phased current metering relay.
• Measures on current with 3-phased current metering transformers, type A74-.. ...
• Measures if all 3-phase currents are within set limits.
• Upper and lower limits separately adjustable.
• Output: 10 A SPDT relay.
• For mounting on DIN-rail in accordance with DIN/EN 50 022.
• H4-housing.
• LED-indication for power supply and output ON.
• AC power supply 2-phases.
