Carlo Gavazzi Dupline Fieldbus Channel Generator G34960012700

Carlo Gavazzi Dupline Fieldbus Channel Generator, Interface For Idec Microsmart Series PLCs, H4 Housing Din Rail Type, Supply: 20-30VDC.

G 3495 0012 is designed as a cost-effective solution for interfacing Dupline I/O’s to an IDEC PLC. It performs three functions: Dupline channel generator, power supply synchronization (enables 3-wire system with supply) and RS232/RS422/RS485 interface.

General Characteristics

• Plug and play: Automatic communication with specific PLC/Controllers.
• Built-in normal Dupline Channel Generator.
• 128 I/O’s and DC power supply on 3 wires.
• RS232/RS422/RS485 port for interfacing to control system.
• Split-I/O mode selectable (128 inputs and 128 outputs).
• LED-indications for supply, Dupline carrier and Com-port Tx.
• Galvanically isolated Com-port supplied by internal DC/DC converter.
