Carlo Gavazzi Current Transformer 1-Phase E83-2050

Carlo Gavazzi Current Transformer 1-Phase AC, Input: 0-50A AC (7 Ranges), Output: 0-20mA.

Small AC current metering transformer with 7 knob selectable ranges. Output from the transformer is 4-20 mADC in accordance with IEC 60381-1. Can be used with relays DIB01, PIB01, DIC01 or PIC01 or directly connected to a PLC. Power supply ON is indicated by a green LED. 12 mm hole for isolated current carrying wire makes it suitable for most applications. For mounting on DIN-rail or directly on surface by screws.

General Characteristics

• 7 input ranges in one unit: 0 - 5 AAC.
• 0 - 10 AAC.
• 0 - 15 AAC.
• 0 - 20 AAC.
• 0 - 25 AAC.
• 0 - 30 AAC.
• 0 - 50 AAC.
• Output 4-20 mADC.
• Easy interface to PLC or set point relays.
• For mounting on DIN-rail in accordance with DIN/EN 50 022.
• 22.5 mm small Euronorm housing.
