Carlo Gavazzi Conductive Sensor Level Controller Din-Rail CLD2EB1BU24

Carlo Gavazzi Conductive Sensor Level Controller, 2-Point Level Charging/Discharging, Sensitivity Adjust 250-500K Ohm, SPDT, Din-Rail, Supply: 24-240VAC/VDC.

μ-Processor based level controller for liquids with a wide sensitivity range (like sewage water, chemicals, salt water etc.). Max./min. control of charging/discharging. The sensitivity is adjustable by means of the potentiometer. 1 x 8A SPDT relay output.

General Characteristics

• Conductive level controller.
• Sensitivity adjustment from 250 Ohm to 500K Ohm.
• For filling or emptying applications.
• Low-voltage AC electrodes.
• Easy installation on DIN rails.
• Rated operational voltage: 24 to 240 VAC/DC.
• Output 1 x 8A/250 VAC SPDT relay.
• LED indication for: Output ON and Power ON.
