Carlo Gavazzi Conductive Sensor Level Controller Din-Rail CLD2EA1C115

Carlo Gavazzi Conductive Sensor Level Controller, 2-Point Level Charging/Discharging, Sensitivity Adjust 250-500K Ohm, DPDT, Din-Rail, Supply: 115VAC.

μ-Processor based level controller for liquids with a wide sensitivity range (like sewage water, chemicals, salt water etc.). Max./min. control of charging/discharging. The sensitivity is adjustable by means of the potentiometer and the rotary switch. 2 x 8A DPDT relay output.

General Characteristics

• Conductive level controller.
• Sensitivity adjustment from 250 Ohm to 500K Ohm.
• For filling or emptying applications.
• Low-voltage AC electrodes.
• Easy installation on DIN rails or with 11 pin circular plug.
• Rated operational voltage: 24 VAC/DC, 115 VAC or 230 VAC.
• Output 2 x 8A/250 VAC DPDT relay.
• LED indication for: Output ON and Power ON.
