Autonics Counter/Timer 4 Digits W72xH72mm, FX4

Autonics Counter / Timer, 4 Digits LED, DIN W72xH72mm, Single Preset, Supply: 100-240VAC, Contact Output: 1x Relay SPDT (1c), Solid State Output: 1x NPN

DIN W72×H72, W48×H96, W144×H72mm of up/down counter/timer FX/FXH/FZL series provides 1cps/30cps/2kcps/5kcps of counting speed and supports NPN/PNP input selecting function equipped counter/timer. Also, the series is possible to set various up/down counting modes so that various user applications can be supported. Diverse size option is another feature of this series to increase user convenience.

General Characteristics

• Easy to select 36 kinds of input operation mode or 20 output operation modes by internal DIP switch.
• Upgraded counting speed: 1cps/30cps/2kcps/5kcps
• Selectable voltage input (PNP) or No voltage input (NPN)
• Addition of Up/Down input mode
• Wide range of power supply : 100-240VAC 50/60Hz, 12-24VAC/DC
• Selectable Counter/Timer by internal DIP switch
• Various time ranges
• Built-in Microprocessor
